Delta ADP-240KB BA 5V,9V,15V,20V,28V,36V,48V 240W 3A,3A,3A,5A,5A,5A,5A Adapter ADP Series

Tech Specs

Output Current

3A,3A,3A,5A,5A,5A,5A

Output Voltage

5V,9V,15V,20V,28V,36V,48V

Output Power

240W

Line Regulation

± 5%

Load Regulation

± 5%

PARD

< 350 mV pk-pk (5V/9V/15V/20V) @ 25°C
< 450 mV pk-pk (28V) @ 25°C
< 500 mV pk-pk (36V) @ 25°C
< 600 mV pk-pk (48V) @ 25°C

Hold-up Time

> 16 ms @ 100 Vac, 100% load

Rise Time

< 40 ms @ 100~240 Vac, 100% load, 5V only

Peak Power

5V: > 4.5V @ 110% Load, 10ms, 100~240 Vac
> 4.5V @ 125% Load, 2ms, 100~240 Vac
> 4.5V @ 150% Load, 1ms, 100~240 Vac

9V: > 8.1V @ 110% Load, 10ms, 100~240 Vac
> 8.1V @ 125% Load, 2ms, 100~240 Vac
> 8.1V @ 150% Load, 1ms, 100~240 Vac

15V: > 13.5V @ 110% Load, 10ms, 100~240 Vac
> 13.5V @ 125% Load, 2ms, 100~240 Vac
> 13.5V @ 150% Load, 1ms, 100~240 Vac

20V: > 18V @ 110% Load, 10ms, 100~240 Vac
> 18V @ 125% Load, 2ms, 100~240 Vac
> 18V @ 150% Load, 1ms, 100~240 Vac

28V: > 25.2V @ 110% Load, 10ms, 100~240 Vac
> 25.2V @ 125% Load, 2ms, 100~240 Vac
> 25.2V @ 150% Load, 1ms, 100~240 Vac

36V: > 32.6V @ 110% Load, 10ms, 100~240 Vac
> 32.6V @ 125% Load, 2ms, 100~240 Vac
> 32.6V @ 150% Load, 1ms, 100~240 Vac

48V: > 43.4V @ 110% Load, 10ms, 100~240 Vac
> 43.4V @ 125% Load, 2ms, 100~240 Vac
> 43.4V @ 150% Load, 1ms, 100~240 Vac

Nominal Input Voltage

100-240 Vac

Input Voltage Range

90-264 Vac

Nominal Input Frequency

50-60 Hz

Input Frequency Range

47-63Hz

Input Current

3.5 A max. @ 100 Vac
2.5 A @ 240 Vac

Inrush Current

Fuse I2t < 22% @ Cold Start

Leakage Current

80 uA max. @ 240 Vac/50 Hz

Average Efficiency

5V ≧ 81.39% ; 9V ≧ 86.62% ; 15V ≧ 87.73% ; 20V ≧ 88% ; 28V ≧ 88% ; 36V ≧ 88% ; 48V ≧ 88%@ 115 Vac & 230 Vac

No Load Power Consumption

0.2 W @ 115 Vac & 230 Vac

Case Chassis / Cover PC
Indicator N/A
Cooling System Convection
Input Terminal C6
Output Terminal Type-C, Length: 1800 ±50 mm
Signal Terminal -
Noise Sound Pressure Level (SPL) -
Input/Output Terminal -
Signal -
Mounting Rail -
Wire -
Protection Structure -
Terminal -
Unit Weight 0.56 (0.00 lb)	Dimensions 162 x 72 x 23 mm 6.38” x 2.83” x 0.91”

Operating Temperature

0°C to +35°C

Storage Temperature

-20°C to +80°C

Operating Humidity

5%-90% RH (non-condensing)

Shock Test (Non-Operating)

50 G, 11 ms, 1 shock for each direction

Vibration (Non-Operating)

5-500 Hz, 2.09 Grms, 20 mins, one cycle for each three axis

Operating Altitude

5,000 meters (16,400 feet)

Overvoltage

<8V @ 5V ; <15V @ 9V ; <20V @ 15V ; <26V @ 20V, <37V @ 28V ; <46V @ 36V ; <60V @ 48V, Latch mode

Overload / Overcurrent

<5.5A @ 5V/9V/15V
<8A @ 20V/28V/36V/48V Latch mode

Over Temperature

Latch mode

Short Circuit

Latch mode

Protection Against Shock

Class I

Pollution Degree

MTBF

> 80,000 hrs. at Input: 100/240 Vac, Output: 100% load, Ta: 25°C

Expected Cap Life Time

13140hours (85% load, 100Vac & 240Vac) @ 35°C

Case Temperature Rise

< 60°C @ 100/240Vac, Output: 100% load, Ta: 35°C

Electrical Safety

IEC/EN 62368-1, 60950
BSMI CNS 13438, 14336-1, 15663
PSE J62368-1, J55032, J3000
UL 62368-1, CSA 62368-1
PSB IEC 62368-1:2014, 60950-1:2005+A1:2009+A2:2013

Comply with EMC Directive 2014/30/EU, the Low Voltage Directive 2014/35/EU, RoHS Directive 2011/65/EU+ (EU) 2020/659 and Commission Regulation (EU) 2019/1782, ErP Directive

Galvanic Isolation

I/P to O/P: 3000 Vac

Emission

EN 55032 Criteria Class B

Immunity

Electrostatic Discharge IEC 61000-4-2
Radio Frequency Electromagnetic Field IEC 61000-4-3
Electrical Fast Transient IEC 61000-4-4
Surge IEC 61000-4-5
Radio Frequency Common Mode IEC 61000-4-6
Power Frequency Magnetic Fields IEC 61000-4-8
Voltage Dips IEC 61000-4-11

Harmonic Current Emissions

IEC 61000-3-2
The power consumption of EUT is less than 75W and no limits apply

Voltage Fluctuation and Flicker

IEC 61000-3-3
