2-60V
2100W
90-264Vac
254 x 127 x 40.5 mm
10.00” x 5.00” x 1.59”
2 kg (4.41 lb)
2-60V
2100W
90-264Vac
254 x 127 x 40.5 mm
10.00” x 5.00” x 1.59”
2 kg (4.41 lb)
|
Output Current
|
|
Output Voltage
2-60V
|
|
Output Voltage Range
|
|
Output Voltage Adjustment Range
-
|
|
Output Power
2100W
|
|
Output Current Adjustment Range
|
|
Max Output Voltage
|
|
Buffering Time
-
|
|
Line Regulation
± 0.5%
|
|
Load Regulation
± 1%
|
|
PARD
-
|
|
Start-up Time
3000ms @ 115Vac
|
|
Hold-up Time
12ms @ rated load, with nominal input range
|
|
Dynamic Response (Overshoot & Undershoot O/P Voltage)
± 5% @ with 50-100% load change
|
|
Start-up with Capacitive Loads
-
|
|
Remote ON/OFF
-
|
|
Protective Device
-
|
|
Voltage Drop Between Input and Output
-
|
|
Residual Ripple/PARD (20MHz)
-
|
|
Residual Ripple
-
|
|
Max. Power
-
|
|
Ripple & Noise
< 1% Vrated pk-pk
|
|
LED System Voltage Range in CC Mode
-
|
|
Rise Time
100ms
|
|
Power Boost Duration
-
|
|
Power Boost Recovery Time
-
|
|
Nominal Input Voltage
100-240Vac
|
|
Input Voltage Range
90-264Vac
|
|
Max Input Voltage
-
|
|
Nominal Input Frequency
50-60Hz
|
|
Input Frequency Range
47-63Hz
|
|
Nominal DC Input Voltage
|
|
DC Input Voltage Range
-
|
|
Input Current
< 15A
|
|
Input Power (Standby Mode)
-
|
|
Efficiency at 100% load
90% @ 115Vac, 93% @ 230Vac
|
|
Inrush Current
< 40A
|
|
Charging Time
-
|
|
Power Factor at 100% load
> 0.95 @ 115V/50Hz, 230V/50Hz
|
|
Leakage Current
< 300uA Normal Condition,
< 1mA Single Fault Condition |
|
Nominal Current
-
|
|
Total Harmonic Distortion
-
|
|
Power Dissipation
-
|
|
Efficiency @ 10% load
-
|
|
Case Chassis / Cover
SGCC
|
|
|
Indicator
-
|
|
|
Cooling System
-
|
|
|
Input Terminal
-
|
|
|
Output Terminal
-
|
|
|
Signal Terminal
-
|
|
|
Noise Sound Pressure Level (SPL)
-
|
|
|
Input/Output Terminal
-
|
|
|
Signal
-
|
|
|
Mounting Rail
-
|
|
|
Wire
-
|
|
|
Protection Structure
-
|
|
|
Terminal
-
|
|
|
Unit Weight
2 kg (4.41 lb)
|
Dimensions
254 x 127 x
40.5 mm
10.00” x 5.00” x 1.59” |
|
Vibration (Operating)
-
|
|
Shock Test (Operating)
-
|
|
Operating Temperature
-20°C to +70°C
|
|
Storage Temperature
-40°C to +85°C
|
|
Power De-rating
-
|
|
Operating Humidity
5-95% RH (Non-Condensing)
|
|
Shock Test (Non-Operating)
50G, 11ms, 3 shocks for each direction
|
|
Vibration (Non-Operating)
5-500Hz, 2Grms, 20 minute for each three axis
|
|
Storage Humidity
-
|
|
Operating Altitude
Up to 5,000 meters
|
|
Pollution Degree
-
|
|
Bump Test (Operating)
-
|
|
Over Voltage Category
-
|
|
Corrosion
-
|
|
Overvoltage
Latch off. Reset by recycling AC or through I2C
Programmable in 110% to 130% rated output voltage range through I2C. |
|
Overload / Overcurrent
Hiccup Mode (Non-Latching, Auto-Recovery)
Programmable in 110% to 130% rated output current range through I2C. |
|
Over Temperature
Latch off
|
|
Short Circuit
Hiccup Mode (Non-Latching, Auto-Recovery)
|
|
Reverse Polarity Protection
-
|
|
Degree of Protection
-
|
|
Protection Against Shock
-
|
|
Input Polarity Protection
-
|
|
Battery Polarity Protection
-
|
|
Wrong Battery Voltage Protection
-
|
|
Deep Discharge Protection
-
|
|
Overload
-
|
|
Overcurrent
-
|
|
Internal Fuse
-
|
|
Insufficient Input Voltage Protection
-
|
|
Safety Certificate
-
|
|
Electrical Safety
IEC 62368-1 CB report
UL 62368-1+CAN/CSA 62368-1 CQC GB 17625.1; GB 4943.1; GB/T 9254.1 |
|
CE
In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU EN 60601-1: 2006 + A11: 2011 + A1: 2013 + A12: 2014 & EN 60601-1-2: 2015
|
|
Medical Safety
IEC 60601-1 CB report
UL 60601-1+CAN/CSA 60601-1 |
|
Galvanic Isolation
Input to Output (2xMOPP): 4000 Vac
Input to Ground (1xMOPP): 1500 Vac Output to Ground: 500 Vac (Type B application rated) Output to Output: 500 Vac |
|
Industrial Control Equipment
-
|
|
Hazardous Location / ATEX
-
|
|
II 3 G ATEX 2014/34/EU
-
|
|
Electrical Equipments of Machines
-
|
|
Electrical Equipment for Use in Electrical Power Installations
-
|
|
Safety Entry Low Voltage
-
|
|
Maritime
-
|
|
Material and Parts
-
|
|
Isolation Resistance
-
|
|
PE Resistance
-
|
|
UKCA
In conformance with Electrical Equipment (Safety) Regulations 2016, and Electromagnetic Compatibility Regulations 2016, Medical Devices Regulations 2002(UK MDR 2002)
|
|
Certificates for Other Countries
-
|
|
BIS
-
|
|
KC
-
|
|
Electrical Equipment for Measurement, Control, and Laboratory Use
-
|
|
ITE Safety
-
|
|
SIL3
-
|
|
Emission
EN/BS EN 55011, EN/BS EN 55032,
FCC Title 47:Class B |
|
Immunity
-
|
|
Harmonic Current Emissions
IEC61000-3-2 Meet Class A limit
|
|
Voltage Fluctuation and Flicker
-
|
|
ESD Immunity
-
|
|
Radiated Immunity
-
|
|
EFT
-
|
|
Surge
-
|
|
Conducted Immunity
-
|
|
Magnetic Field
-
|
|
Voltage Dips
-
|
|
Component Power Supply for General Use
-
|
