LNA-600A20AFCFA

DIN Rail

LNA ARENA SPORT Series

LNA-600A20AFCFA

Output Voltage

200-550V

Output Power

600W

Output Current

2A

Input Voltage Range

198-440Vac

Dimensions (H x W x D)

285 x 100 x 49 mm

11.22” x 3.94” x 1.93”

Unit Weight

2.2 kg (4.85 lb)

Highlights & Features
  • Output power: max 600W
  • Wide input voltage: 198-440VAC
  • Ultra high Efficiency 97.5%
  • Control method: DALI-2 & D4i
  • Programmable output current range 700-2000 mA
  • Constant Light Output (CLO) function
  • Smart Timer Dimming (STD)
  • Wide dimming range 0.1-100%
  • High-accuracy integrated power metering
  • Input surge protection: DM 6kV; CM 10kV
  • Max signal control distance 300 meters
  • Reliable IP66 input/output connectors
  • Low current ripple (typ.1%) for HDTV broadcasting
  • Afterglow effect free
    • Applications
    LNA-600A20AFCFA
    LNA-600A20AFCFA

    DIN Rail

    LNA ARENA SPORT Series

    LNA-600A20AFCFA

    Highlights & Features
  • Output power: max 600W
  • Wide input voltage: 198-440VAC
  • Ultra high Efficiency 97.5%
  • Control method: DALI-2 & D4i
  • Programmable output current range 700-2000 mA
  • Constant Light Output (CLO) function
  • Smart Timer Dimming (STD)
  • Wide dimming range 0.1-100%
  • High-accuracy integrated power metering
  • Input surge protection: DM 6kV; CM 10kV
  • Max signal control distance 300 meters
  • Reliable IP66 input/output connectors
  • Low current ripple (typ.1%) for HDTV broadcasting
  • Afterglow effect free
    • Output Voltage

    200-550V

    Output Power

    600W

    Output Current

    2A

    Input Voltage Range

    198-440Vac

    Dimensions

    285 x 100 x 49 mm

    11.22” x 3.94” x 1.93”

    Unit Weight

    2.2 kg (4.85 lb)

    Applications

    Download

    Download

    Datasheet

    Uploaded on 23-Mar-2026


    Uploaded on 01-Jul-2025

    Mechanical Drawing

    Uploaded on 11-Mar-2025

    .DXF

    Uploaded on 11-Mar-2025

    CB

    Uploaded on 10-Mar-2025

    CCC

    Uploaded on 10-Mar-2025

    CE

    Uploaded on 12-Mar-2025

    ENEC

    Uploaded on 10-Mar-2025

    RCM

    Uploaded on 10-Mar-2025

    UKCA

    Uploaded on 12-Mar-2025

    Tech Specs

    Tech Specs

    Output Current
    2A
    Output Voltage
    200-550V
    Output Voltage Range
    200-550Vdc
    Output Voltage Adjustment Range
    -
    Output Power
    600W
    Output Current Adjustment Range
    0.7-2A
    Max Output Voltage
    600Vdc
    Buffering Time
    -
    Line Regulation
    -
    Load Regulation
    -
    PARD
    -
    Start-up Time
    -
    Hold-up Time
    -
    Dynamic Response (Overshoot & Undershoot O/P Voltage)
    -
    Start-up with Capacitive Loads
    -
    Remote ON/OFF
    -
    Protective Device
    -
    Voltage Drop Between Input and Output
    -
    Residual Ripple/PARD (20MHz)
    -
    Residual Ripple
    -
    Max. Power
    -
    Ripple & Noise
    -
    LED System Voltage Range in CC Mode
    -
    Rise Time
    -
    Power Boost Duration
    -
    Power Boost Recovery Time
    -
    Peak Power
    -
    Nominal Input Voltage
    220-400Vac
    Input Voltage Range
    198-440Vac
    Max Input Voltage
    -
    Nominal Input Frequency
    50/60 Hz
    Input Frequency Range
    47-63Hz
    Nominal DC Input Voltage
    DC Input Voltage Range
    -
    Input Current
    2.85 A At 220 Vac, 25°C, 600 W output
    1.54 A At 400 Vac, 25°C, 600 W output
    Input Power (Standby Mode)
    0.40 W At 230 Vac/50 Hz, Dim OFF, in compliance with Erp (EU) 2019/2020
    0.89 W At 400 Vac, Dim OFF
    Efficiency at 100% load
    96.2% At 220 Vac, 25°C, 300 V/2 A
    96.6% At 220 Vac, 25°C, 550 V/1.1 A
    96.8% At 400 Vac, 25°C, 300 V/2 A output
    97.5% At 400 Vac, 25°C, 550 V/1.1 A output
    Inrush Current
    8A At 220 Vac，50% Apk to 50% Apk time: 2 ms
    15A At 400 Vac，50% Apk to 50% Apk time: 2 ms
    Charging Time
    -
    Power Factor at 100% load
    0.99 At 220 Vac, 25°C, 600 W output
    0.98 At 400 Vac, 25°C, 600 W output
    Leakage Current
    -
    Nominal Current
    -
    Total Harmonic Distortion
    8% At 220 Vac, 25°C, 300 V/2 A output
    13% At 400 Vac, 25°C, 300 V/2 A output
    Power Dissipation
    -
    Efficiency @ 10% load
    -
    Case Chassis / Cover
    Aluminum case, color: anodized (Nature)
    Indicator
    -
    Cooling System
    Natural Convection
    Input Terminal
    Line(L): Brown, Neutral(N): Blue, PE: Yellow & Green,
    SOOW & H07RN-F & 2PNCT, 3C/1.0 mm² (17AWG), Length: 300mm±25mm
    Output Terminal
    Positive(V+): Brown, Negative(V-): Blue, PE: Yellow & Green,
    SOOW & H07RN-F & 2PNCT, 3C/1.0 mm² (17AWG), Length: 240mm±25mm
    Signal Terminal
    -
    Noise Sound Pressure Level (SPL)
    < 24dBA at 30cm distance
    Input/Output Terminal
    -
    Signal
    -
    Mounting Rail
    -
    Wire
    -
    Protection Structure
    -
    Terminal
    -
    Unit Weight
    2.2 kg (4.85 lb)
    Dimensions
    285 x 100 x 49 mm
    11.22” x 3.94” x 1.93”
    Vibration (Operating)
    -
    Shock Test (Operating)
    -
    Operating Temperature
    -40 ~+60°C
    Storage Temperature
    -40°C to +85°C
    Power De-rating
    -
    Operating Humidity
    10% to 90% RH (Non-Condensing)
    Shock Test (Non-Operating)
    -
    Vibration (Non-Operating)
    IEC 60068-2-6, Random: 5 Hz to 10 Hz (1G);
    30 min per axis for all X, Y, Z direction
    Storage Humidity
    10% to 90% RH (Non-Condensing)
    Operating Altitude
    -
    Pollution Degree
    -
    Bump Test (Operating)
    -
    Over Voltage Category
    -
    Corrosion
    -
    Acoustic Noise
    -
    Overvoltage
    -
    Overload / Overcurrent
    -
    Over Temperature
    -
    Short Circuit
    -
    Reverse Polarity Protection
    -
    Degree of Protection
    IP66
    Protection Against Shock
    -
    Input Polarity Protection
    -
    Battery Polarity Protection
    -
    Wrong Battery Voltage Protection
    -
    Deep Discharge Protection
    -
    Overload
    -
    Overcurrent
    -
    Internal Fuse
    -
    Insufficient Input Voltage Protection
    -
    MTBF
    475 khrs at Ta=+45°C Telcordia SR-332
    Expected Cap Life Time
    50,000 hours applicable for 220 Vac to 400 Vac(50/60 Hz) @100% of load, @ Ta 45°C
    Safety Certificate
    ENEC:
    EN 61347-2-13:2014, EN 61347-2-13/A1:2017
    EN 61347-1:2015, EN 61347-1:2015/A1:2021
    EN IEC 62384:2020

    RCM:
    AS 61347-2-13: 2018
    AS/NZS 61347-1: 2016+A1

    CB report: EN 61347-1:2015, EN 61347-1:2015/A1:2021
    EN 61347-2-13:2014, EN 61347-2-13/A1:2017

    CCC: GB 19510.1, GB 19510.14
    Electrical Safety
    -
    CE
    CE Declaration of Conformity
    Medical Safety
    -
    Galvanic Isolation
    -
    Industrial Control Equipment
    -
    Hazardous Location / ATEX
    -
    II 3 G ATEX 2014/34/EU
    -
    Electrical Equipments of Machines
    -
    Electrical Equipment for Use in Electrical Power Installations
    -
    Safety Entry Low Voltage
    -
    Maritime
    -
    Material and Parts
    -
    Isolation Resistance
    -
    PE Resistance
    -
    UKCA
    BS EN 61347-2-13: 2014+A1:2017
    Certificates for Other Countries
    -
    BIS
    -
    KC
    -
    Electrical Equipment for Measurement, Control, and Laboratory Use
    -
    ITE Safety
    -
    SIL3
    -
    Emission
    Radiated Emission: EN55015, GB/T17743
    Conducted Emission: EN55015, GB/T17743
    Immunity
    -
    Harmonic Current Emissions
    EN61000-3-2, GB 17625.1
    Voltage Fluctuation and Flicker
    EN61000-3-3
    ESD Immunity
    EN 61000-4-2
    Radiated Immunity
    -
    EFT
    EN 61000-4-4
    Surge
    (AC Mains)
    EN 61000-4-5
    - Common Mode: 10kV (Line to Earth, Neutral to Earth)
    - Differential Mode: 6kV (Line to Neutral)
    Conducted Immunity
    -
    Magnetic Field
    EN 61000-4-3
    Voltage Dips
    EN 61000-4-11
    Component Power Supply for General Use
    -
    Nominal Battery Voltage
    -
    Battery Voltage Range
    -
    Battery Capacity
    -
    Battery Charging Mode
    -
    End of Charge Voltage
    -
    Battery Fuse
    -
    Battery Discharging Voltage Range
    -
    Battery Charging Current
    -
    Battery Current Consumption
    -
    Discharging Current
    -
    Recommended Charging Voltage
    -
